George Santayana: "Those who cannot remember the past are condemned to repeat it."

In software engineering:

• Failures expose what happens when good practices are ignored
• Real disasters teach faster than textbook examples
• Every case maps to concepts from our course modules

Today: 5 famous failures analyzed through the lens of Chapters 01-04

By the end of this lecture, you will:

1. Identify how missing requirements caused each failure (Ch04)
2. Explain testing gaps that allowed bugs to escape (Ch03)
3. Recognize code quality issues that contributed to disasters (Ch02)
4. Connect CI/CD and deployment failures to our workflow (Ch01-02)
5. Apply lessons learned to your own projects

Each failure will be analyzed using these concepts.

Therac-25: Radiation therapy machine (1985-1987)

• Delivered 100x intended radiation doses to patients
• 6 accidents: 4 deaths, 2 serious injuries
• Root cause: Software-only safety (hardware interlocks removed)

Key insight: The Therac-6 and Therac-20 had similar software bugs, but hardware interlocks prevented accidents. The Therac-25 removed those interlocks.

Leveson & Turner, IEEE Computer 1993

Operator workflow (fast typist):
1. Select treatment mode: "X" (X-ray)
2. Wait for screen...
3. Change mode to "E" (Electron) within 8 seconds
4. Press "Set" button

Bug: Software updated mode internally,
     but hardware turntable hadn't moved yet.
     → High-energy beam fired through wrong collimator

This is a classic race condition - two processes accessing shared state without proper synchronization.

Missing Stakeholder Analysis:

• Manufacturer assumed operators would be slow/careful
• No requirement: "System shall prevent beam if turntable not in position"

No Traceability:

• Safety requirements not linked to test cases
• No FR/NFR documentation for race condition handling

Implicit Assumptions (Ch04 "Design by Contract"):

Precondition (undocumented): Mode change takes > 8 seconds
Reality: Fast operators could change in < 8 seconds

No Boundary Value Analysis:

• What happens at the boundary where software/hardware states diverge?
• No tests for "mode change during turntable movement"

Missing Equivalence Classes:

Class	Tested?	Example
Normal operation (slow)		Mode → Wait 10s → Set
Fast mode change		Mode → Change < 8s → Set
Concurrent operations		Multiple state changes

100% code coverage ≠ safe system (Ch03 Coverage lesson)

Software Reuse Without Verification:

• Code reused from Therac-6/20 without re-testing assumptions
• Original bugs were masked by hardware, not fixed

No Static Analysis:

• Race conditions detectable by modern tools
• No equivalent of Ruff/Pyright for concurrent code review

Dead Code Problem:

• Error handling code existed but returned cryptic "MALFUNCTION" numbers
• Operators learned to ignore them (like ignoring linter warnings!)

Think about your Road Profile Viewer:

1. What implicit assumptions have you made about user behavior?
2. Do you have tests for "unusual" user interaction patterns?
3. If your find_intersection() has a bug, what's the worst outcome?

Therac operators were blamed initially - "user error." Sound familiar?

Ariane 5 Flight 501 (June 4, 1996)

• First launch of Europe's new heavy-lift rocket
• Exploded 37 seconds after liftoff
• Loss: $370 million (rocket + 4 satellites)

Root cause: A 64-bit floating point → 16-bit integer conversion overflow

ESA Inquiry Board Report

-- Inertial Reference System (Ada code)
BH : Integer_16;  -- Horizontal Bias, 16-bit signed

-- Conversion that caused the crash:
BH := Integer_16(Floating_Point_Value);
-- Ariane 4: Value always < 32,767 ✓
-- Ariane 5: Value reached 32,768+ → OVERFLOW!

The overflow triggered an exception → System shutdown → Rocket lost control

Both primary AND backup systems crashed (identical software!)

Classic Boundary Value Failure:

Parameter	Ariane 4 Range	Ariane 5 Range	Tested?
Horizontal velocity	0 - 32,000	0 - 64,000
BH (Horizontal Bias)	Fits in 16-bit	Overflows!

From our Ch03 lecture:

"Test at boundaries: minimum, maximum, just inside, just outside"

The 16-bit boundary (32,767) was never tested with Ariane 5's trajectory!

Software Reuse Without Requirement Review:

• Ariane 4 SRI (Inertial Reference System) reused "as-is"
• No requirements audit for new flight profile

Missing NFR (Non-Functional Requirement):

NFR-FLIGHT-001: System shall handle horizontal velocities
               up to 70,000 units (Ariane 5 max + margin)

ESA Report: "The requirement that BH should fit in 16 bits was stated in an obscure part of a document. In the code itself, it was nowhere to be found!"

This is exactly what Pyright catches!

# Python equivalent of the Ariane bug:
def calculate_bias(velocity: float) -> int:
    return int(velocity)  # Pyright: OK, but dangerous!

# Better with explicit bounds checking:
def calculate_bias(velocity: float) -> int:
    if velocity > 32767:
        raise ValueError(f"Velocity {velocity} exceeds 16-bit range")
    return int(velocity)

Modern type systems can prevent these bugs - Ada had types, but the checks were disabled for "performance"!

The conversion code wasn't even needed after liftoff!

Timeline:
- T-0: Liftoff
- T+37s: BH calculation overflows (code still running)
- T+37s: Exception → Shutdown
- T+40s: This code's purpose ends anyway!

The alignment function served NO PURPOSE after liftoff.
It was kept running for 40 seconds based on Ariane 4 requirements.

Ch02 lesson: Dead code isn't just clutter - it's a liability.

From your Road Profile Viewer experience:

1. Have you reused code from another project without checking assumptions?
2. What's the valid range for angle_degrees in find_intersection()?
3. Do you have tests for boundary values like angle = 360.0?

The Ariane team had 10 years of "working" code. It only worked because the environment was different.

Mars Climate Orbiter (September 23, 1999)

• NASA spacecraft to study Martian climate
• Lost during Mars orbit insertion
• Passed 57 km above surface instead of planned 150 km
• Burned up in Martian atmosphere

Root cause: One team used metric (N·s), another used imperial (lbf·s)

NASA Mishap Investigation Report

Lockheed Martin software (SM_FORCES):
  Output: Thruster impulse in pound-force seconds (lbf·s)

NASA navigation software:
  Expected: Thruster impulse in Newton seconds (N·s)

Conversion factor: 1 lbf·s = 4.45 N·s

Result: Navigation thought thrusters were 4.45x weaker than reality
        → Trajectory corrections accumulated wrong → Lost spacecraft

A classic interface contract violation.

Missing Interface Contract (Design by Contract):

# What should have existed:
class ThrusterData:
    """
    Precondition: impulse values in SI units (Newton-seconds)
    Postcondition: returns trajectory correction in meters
    """
    impulse_ns: float  # Explicit unit in type/name!

NASA Report: "The Software Interface Specification (SIS) stated metric units, but the code produced imperial units."

Ch04 lesson: Requirements must be explicit AND verified!

Unit Tests Passed, Integration Failed:

Test Level	Lockheed	NASA	Combined
Unit tests	Pass	Pass	N/A
Module tests	Pass	Pass	N/A
Integration tests	N/A	N/A	Never done!

From Ch03 Testing Pyramid:

"Unit tests verify functions work. Integration tests verify they work together."

End-to-end verification was "too late" and "too weak."

Modern Python would catch this:

# Bad: Implicit units
def calculate_impulse() -> float:
    return 4.5  # lbf·s? N·s? Who knows!

# Good: Explicit units via types
from dataclasses import dataclass

@dataclass
class NewtonSeconds:
    value: float

def calculate_impulse() -> NewtonSeconds:
    return NewtonSeconds(4.5)  # Clear and type-safe!

Units as types = impossible to mix! (Pyright would catch mismatches)

NASA Investigation Board Chairman:

"The problem was not the error. It was the failure of NASA's systems engineering and checks and balances to detect the error."

Ch02 CI/CD lesson: Quality gates must catch errors automatically!

• No automated unit checks on interface values
• No range validation ("is this impulse value plausible?")
• Manual reviews missed it for 9+ months of flight

In your Road Profile Viewer:

1. What are the interfaces between your modules?
2. Do you have explicit contracts for function inputs/outputs?
3. What happens if find_intersection() receives coordinates in different units?

Both Lockheed and NASA code worked perfectly - they just didn't work together.

Knight Capital (August 1, 2012)

• Deployed new trading software to 8 servers
• 1 server missed the deployment
• Old "dead" code on that server triggered by new feature flag
• System executed 4 million erroneous orders in 45 minutes
• Loss: $460 million (company nearly bankrupt)

SEC Enforcement Order

2005: "Power Peg" feature uses flag X in trading router
2007: Power Peg deprecated, but code left in place
2012: New "RLP" feature reuses flag X

Deployment to 8 servers:
- Servers 1-7: New code with RLP ✓
- Server 8: Old code with Power Peg still present ✗

August 1, 2012:
- Orders with flag X sent to Server 8
- Server 8 runs Power Peg (never reports completion)
- Server 8 buys/sells infinitely → $460M loss

No Automated Deployment (Ch02 CI/CD):

# What should have existed:
deploy:
  script:
    - for server in $(cat servers.txt); do
        deploy_to_server $server
        verify_deployment $server
      done
    - run_integration_tests
    - if tests_fail; then rollback_all; fi

Reality: Manual deployment with no verification checklist

SEC Report: "Knight did not have adequate safeguards to limit risks."

Remember from Ch02:

"Dead code costs: Must update for API changes, readers must understand it, may use outdated logic if revived."

Knight Capital's dead code:

• "Power Peg" function unused since 2007
• Left in codebase for 5 years
• Activated accidentally by flag reuse

Our linting rule (Ruff F401/F841): Remove unused code!

What tests were missing:

Test Type	Purpose	Knight Had?
Smoke test	Basic functionality after deploy
Canary deploy	Test on subset first
Config verification	All servers have same code
Integration test	New feature with real system

SEC finding: "97 automated emails warned of errors before market open. Knight did not act on them."

Git would have helped:

# Proper deployment workflow:
git tag v2.1.0-rpl
git push origin v2.1.0-rpl

# Deploy same tagged version to ALL servers
for server in production-{1..8}; do
  ssh $server "git checkout v2.1.0-rpl && restart_service"
done

# Verify all servers on same commit:
for server in production-{1..8}; do
  ssh $server "git rev-parse HEAD"
done

Knight's reality: Manual file copy, no version tracking

For your development workflow:

1. How do you deploy code? Is it automated and repeatable?
2. Do you have dead code in your project? How would you know?
3. What's your rollback plan if a deployment fails?

Knight's technician made one mistake. The system should have caught it.

HealthCare.gov (October 1, 2013)

• Federal health insurance marketplace launch
• 4 million visitors on day 1
• Only 6 people successfully registered
• Site crashed within 2 hours of launch
• Cost: $500+ million, political disaster

GAO Report GAO-14-694

Launch Day Issues:
1. 250,000 concurrent users (expected: 50,000) → 5x underestimate
2. Database bottlenecks in user registration
3. API timeouts between 60+ connected systems
4. SSL certificate issues
5. Memory leaks causing cascading failures

Root Cause: Big-bang launch without adequate testing

GAO: "CMS launched without verification that systems met performance requirements."

Missing NFRs (Non-Functional Requirements):

GAO: "Task orders issued when key technical requirements were unknown, including number of states and potential enrollees."

60 contracts to 33 different vendors:

Problem: No single system integrator!

CMS thought CGI was the lead integrator.
CGI said: "That was not our understanding."

Result: Nobody owned the integration.
        Nobody was responsible for end-to-end testing.
        Nobody knew if the pieces would fit together.

Ch04 lesson: Clear stakeholder roles and ownership!

The Testing Pyramid Inverted:

What HealthCare.gov had:
     /-------------\
    /  Some Unit   \      ← Individual contractor tests
   /----------------\
  /  ???  Module ???  \    ← Unclear ownership
 /--------------------\
/  NO E2E TESTING!!!   \   ← Never done at scale

GAO: "Systems were not fully tested prior to launch,
     and test documentation was missing key elements."

No Continuous Integration Across Teams:

• Each contractor had their own build process
• No shared CI pipeline
• Integration happened "at the end" (big-bang)
• Key governance review delayed from March to September
  • Just weeks before October launch!

Ch02 lesson: Integrate early and continuously!

After the disaster, they applied our course principles:

1. Small, incremental releases (not big-bang)
2. Continuous monitoring and alerts
3. Clear ownership of each component
4. Performance testing before each release
5. Rapid rollback capability

By December 2013, the site was working. Same technology, different process.

For your team projects:

1. Who is responsible for integration testing?
2. What happens when multiple people work on the same codebase?
3. Have you tested with realistic load/data volumes?

Every contractor's code worked. The integration was the failure.

Every failure maps to concepts we've covered!

Pattern 1: Implicit Assumptions

• Therac: "Operators are slow"
• Ariane: "Values fit in 16 bits"
• MCO: "Everyone uses metric"

Pattern 2: Testing Gaps

• Boundary values not tested (Ariane)
• Integration not tested (MCO, HCgov)
• Deployment not tested (Knight)

Pattern 3: Process Failures

• No traceability (all cases)
• Dead code kept (Therac, Knight)
• Big-bang releases (HCgov)

For your Road Profile Viewer, check:

How many can you check? What's your priority to fix?

1. Failures are rarely "one bug" - they're systemic process failures
2. Every course concept prevents real disasters:
   • Types prevent MCO (Ch02)
   • Boundary tests prevent Ariane (Ch03)
   • CI/CD prevents Knight (Ch02)
   • NFRs prevent HCgov (Ch04)
3. Tests are executable requirements - if you can't test it, you don't understand it
4. Integration is where systems fail - test modules together, not just alone

Primary Sources:

• Leveson & Turner: Therac-25 Investigation (IEEE 1993)
• ESA: Ariane 501 Inquiry Board Report
• NASA: Mars Climate Orbiter Mishap Report
• SEC: Knight Capital Enforcement Order
• GAO: HealthCare.gov Report (GAO-14-694)

Books:

• Nancy Leveson: Safeware: System Safety and Computers (1995)
• Robert Glass: Software Runaways (1998)
